Christie® Eclipse G3 is the ultimate projector for immersive experiences.
In a class of its own, Eclipse G3 delivers a degree of detail and depth of color not possible with any other projector. This third generation of Eclipse technology is capable of maintaining 30,000 ANSI lumens for the first 50,000 hours. It’s not only brighter and more durable, it’s also more refined, with built-in RGB pure laser illumination and a streamlined, easier-to-install form factor.
Discover the unsurpassed image quality of true HDR performance with the deepest, darkest onscreen blacks imaginable, and up to 20,000,000:1 sequential contrast ratio. Experience richly saturated color and breathtakingly lifelike visuals with Eclipse G3’s expansive color palette, ≈98% of Rec. 2020.
"Video black" is a thing of the past
A unique 6DLP projector, Eclipse G3 displays true blacks without any residual light, dramatically enhancing image quality. It enables the richest visual experiences in fully light-controlled environments. It also reduces system complexity because it eliminates the need for black-level blending adjustments and masking in multi-projector arrays.
Eclipse G3 processes and reproduces true HDR imagery on-screen. It achieves an unparalleled sequential contrast ratio of up to 20,000,000:1 — 100 times Rec. 2100 contrast performance — exceptional detail in the extreme black range, and stunning specular highlights*.
No compromises — only the pinnacle of performance.
Key features
- High frame rate, native 4K performance: Supports up to 120 Hz 2D and active 3D at up to 60 Hz per eye
- Extraordinary reliability and longevity: Designed to maintain 100% brightness for 50,000 hours
- Ease of integration: Eclipse G3 has a simplified form factor with the projector head and light source in one chassis and an external chiller. The improved optical design reduces the risk of dust and dirt intrusion. With the external chiller, the majority of heat and noise is remote from the projector
- Quiet operation: 45dBA (typical)
- Fully field-serviceable: Easy service of the projector and light source
- Built-in warping and blending: Includes Christie Twist™ and supports optional Mystique™ automated camera-based alignment
- LiteLOC technology: Maintains color balance and brightness over time, regardless of fluctuations in ambient temperature
- ILS4 lens compatibility: Compatible with most Christie 4K 3DLP ILS4 lenses
* A specular highlight is a bright spot of light that reflects off a shiny surface. They are important in 3D computer graphics, cinematography and photography.
Quick links
-
Preliminary spec sheet
-
Ultimate contrast
-
A color revolution
Specifications
Up to 20,000,000:1 (sequential)* with ultra-high contrast lenses
Contrast ratio
6DLP
Display type
4K (4096 x 2160)
Resolution
Solid-state RGB pure laser
Illumination type
Maintains 100% brightness for the first 50,000 hours
Illumination performance (hrs)
Omnidirectional
Orientation
* Contrast ratio is up to 10,000,000:1 with high contrast and high brightness lenses.
** Requires ILS4 lens mounting kit (003-005538-XX).
*** Brightness is reduced by approximately 30% with the use of an ultra high contrast lens.
**** Brightness is reduced by up to 30% with the use of the UST lens. Focus drift can occur with this lens when switching between prolonged periods of light and dark content depending on extreme APL changes.
† Hard wired connection is required, requires a 30A (North America) or 32A (EU) circuit breaker capacity. Please refer to local codes.
†† C14 input, requires a 15A breaker. Use of Christie supplied uninterruptible power supply is recommended for the electronics.
††† Requires a 30A breaker capacity.
